LONFA
WP15
| NAME | ITEM | WP15-154F | WP20-168F | WP30-168F-1 | WP40-188F |
| Pump | Inlet and Outlet Inside Dia(mm) | 1.5inch(38) | 2inch(50) | 3inch(80) | 4inch(100) |
| Pump Lift(m) | 17.8 | 23 | 28 | 30 | |
| Suction Height(m) | 7 | 8 | 8 | 8 | |
| Max capacity(m3/hr) | 20 | 26 | 60 | 80 | |
| Engine | Model | 154F | 168F | 168F-1 | 188F |
| Set | Dimension(Lx Wx H)(mm) | 400x300x390 | 485x380x405 | 520x380x450 | 640x465x525 |
| Net Weight(kg) | 12 | 23 | 25 | 42 |
